CCR200 Series
200W fan cooled, 170W conduction cooled, 110W convection cooled AC-DC power supplies for medical (2 x MOPP) or industrial electronics applications
The CCR200 series of compact medical AC-DC power supplies are designed to operate in convection cooled, conduction cooled, and fan cooled applications with power ratings from 110 to 200W. CCR200 offers high efficiency and high power density in a low profile, baseplate cooled design that ensures effective thermal management and quiet operation for noise sensitive applications.
Featuring Class B conducted and radiated emissions, worldwide industrial and medical safety approvals, 2 x MOPP isolation and low leakage currents, the CCR200 is designed for easy integration into a wide range of BF rated medical applications including respiratory care, imaging, patient monitoring, patient treatment, and industrial applications such as process control, test & measurement, and industrial printing.
Features
- 200W fan cooled 170W conduction cooled
- 110W convection cooled
- Single outputs from 12 to 54VDC
- Input range 85 to 264VAC
- 78.6 x 57.9 mm footprint, 25.4mm profile
- Medical (BF) and ITE approvals
- Low patient leakage <75μA
- Low earth leakage <300μA
- High efficiency, up to 94%
- Less than 0.32W no load input power
- -40°C to +80°C operation
- 3 year warranty
| Image | Model Name | Power | Input Voltage | Output Voltage | Output Current | Datasheet | Stock Check | RFQ |
|---|---|---|---|---|---|---|---|---|
 | CCR200PS12 | 200W | Single Phase | 12V | 16.67A | Datasheet | Stock | RFQ |
| CCR200PS15 | 200W | Single Phase | 15V | 13.33A | Datasheet | Stock | RFQ |
| CCR200PS24 | 200W | Single Phase | 24V | 8.33A | Datasheet | Stock | RFQ |
| CCR200PS28 | 200W | Single Phase | 28V | 7.14A | Datasheet | Stock | RFQ |
| CCR200PS30 | 200W | Single Phase | 30V | 6.66A | Datasheet | Stock | RFQ |
| CCR200PS36 | 200W | Single Phase | 36V | 5.67A | Datasheet | Stock | RFQ |
| CCR200PS48 | 200W | Single Phase | 48V | 4.16A | Datasheet | Stock | RFQ |
| CCR200PS54 | 200W | Single Phase | 54V | 3.7A | Datasheet | Stock | RFQ |
